Low failure, minimal maintenance, and foolproof simple operation: The gearbox adopts a non gear transmission method, without the need for oil lubrication, to avoid pollution caused by oil leakage
Changing the tail sliding support to elastic support greatly reduces noise and improves grading performance
The streamline design inside the discharge outlet will not deposit materials and avoid cross contamination
The screen pressing mechanism is simple and convenient, allowing for quick screen replacement
There are two layers of screens and three layers of screens with dual inlet options available
Applied to the grading and secondary circulation crushing process of granular and crushed materials, as well as the cleaning and grading of some particles and powders
| Model | SFJH80×2C | SFJH100×2C | SFJH120×2C | SFJH125×2C | SFJH150×2C |
| Capacity(t/h) | 5-12 | 8-16 | 10-18 | 12-20 | 15-25 |
| Power(kw) | 1.5 | 2.2 | 3 | 4 | 5.5 |
